Part Usage Height (mm) Usage Width (mm) Weight (kg) Working Pressure (bar) Deflated Length (mm) Deflated Width (mm) Deflated Height (mm) Inflation Valve Thread Size
Wedge Type 1 15-45 60-80 0.3 1.5 230 60 50 R 1/4
Wedge Type 2 15-45 80-110 0.4 1.5 230 80 55 R 1/4
Wedge Type 3 30-60 110-170 0.5 1.5 230 110 70 R 1/4
Cone 30-90 Diameter 0.3 1.5 230 7 Diameter 7 Diameter R 1/4
