Adjustment Type Adjustment Range* (mm) Max Load Capacity (kg) Weight of Manhole Ring Lifter** (kg)
Bracket 2 1000 - 1500 2500 102
Bracket 3 900


*Internal manhole ring diameter (attachments available to lift 1800 rings).
** Weight without load.



    The Manhole Ring Lifter is designed to make handling pre-cast concrete rings straightforward, with the excavator operator controlling the gripping and releasing mechanism.

    1. Connect the attachment: Attach the Manhole Ring Lifter to the excavator using a chain sling, following the manufacturer’s instructions and approved lifting arrangements.
    2. Position the lifter: Lower the attachment into the manhole ring or cone, so it engages the internal surface.
    3. Engage the gripping mechanism: Move the lifting hook as instructed to switch the unit into its gripping position.
    4. Lift and position the ring: Once the correct engagement and secure grip have been confirmed, the excavator operator can lift and manoeuvre the ring into position in accordance with the lifting plan.
    5. Release the ring: Once the ring is safely positioned and the load is supported as required, a slight sideways movement of the lifting hook switches the mechanism to the release position.

    The unit has two gripping levels, so you can often lift different ring sizes without adjusting the setting between lifts. Always check the correct configuration, engagement, and release procedure against the manufacturer’s user guide.



FAQs

What is a Manhole Ring Lifter?

A Manhole Ring Lifter is a specialist mechanical lifting attachment that grips pre-cast concrete manhole rings and cones internally. It connects to an excavator via a chain sling and helps the operator handle and position rings without relying on manual handling to guide the load.


Is the Manhole Ring Lifter safe to use?

Reducing the need for manual intervention, and keeping operatives clear of the slewing excavator, means the Manhole Ring Lifter introduces greater safety in handling operations by assigning much of the control to the excavator driver.


Are Manhole Ring Lifters easy to use?

Yes, The Manhole Ring Lifter offers quick, easy and efficient handling for a range of manholes and cones. It attaches to the excavator via a chain sling and the machine operator simply switches the unit from ‘gripping’ to ‘releasing’ by performing a slight side movement of the lifting hook.


What size rings can the unit handle?

The standard attachment accommodates internal ring diameters from 900mm to 1,500mm. Attachments are also available for 1,800mm rings. Confirm the required configuration when enquiring.


What is the maximum load capacity of the Manhole Ring Lifter?

The Groundforce Shorco Manhole Ring Lifter has a maximum handling capacity of 2,500kg. Check the load weight and dimensions, the attachment configuration and the lifting equipment before use.


Is the Manhole Ring Lifter easy to set?

The lifter features two gripping levels, so you can often handle different manhole ring sizes without manually changing the setting between lifts. Check the required configuration before use, per the manufacturer’s instructions.


Is a user guide available for Manhole Ring Lifters?

Yes, a user guide will be provided with every hire and can be requested from Groundforce or can be downloaded from the Groundforce Shorco section of the Groundforce website. A user guide for Manhole Ring Lifters is also available below to download as a PDF.




Do Groundforce offer training courses?

Anyone involved in lifting operations must have the appropriate training, competence and authorisation for their role. Depending on the task, relevant courses may include the CPCS A40 Slinger Signaller course or the NPORS N402 Slinger Signaller course. Excavator operators may also need relevant plant-operation training.



Required training depends on the individual’s responsibilities and the equipment used. Always follow the site lifting plan, applicable requirements and the manufacturer’s instructions.


How does the Manhole Ring Lifter grip and release a ring?

The attachment uses an internal gripping mechanism. The excavator operator switches between gripping and releasing positions by slightly moving the lifting hook sideways, following the procedure in the manufacturer’s user guide.


Does the Manhole Ring Lifter reduce manual handling?

Yes. The attachment mechanically grips and positions concrete manhole rings, reducing the need for operatives to manually handle or guide heavy rings during lifting. Appropriate exclusion zones, communication and safe lifting procedures must still be maintained.
